T6GC,T7GB,T6GCC,T67GCB,T7GBB Series Vane Pumps
Yes
ISO9001 CE
Standard
1 set
Right hand or Left hand
1. Industrial Hydraulic Systems 2. Mobile Equipment (Industrial Vehicles) 3. Construction and Engineering Machinery 4. Metallurgy Industry
Key Shaft and Teeth Shaft
Product Description
T6GC, T7GB, T6GCC, T67GCB, T7GBB Series Vane Pumps offer reliable, high-performance hydraulic solutions for various industrial applications. Designed with precision engineering, they deliver smooth, efficient flow and stable pressure. Featuring compact size, low noise, and easy maintenance, this series ensures durability and consistent operation in demanding environments.
High Efficiency: Optimized vane design ensures excellent volumetric efficiency and minimal internal leakage.
Smooth Operation: Precision machining and balanced components reduce noise and vibration for quieter performance.
Compact & Lightweight: Space-saving design allows easy integration into tight hydraulic systems.
Robust Construction: Durable materials and advanced manufacturing provide long service life and resistance to wear.
Wide Pressure Range: Capable of operating reliably under medium to high hydraulic pressures.
Easy Maintenance: Modular design and accessible components simplify inspection and repairs.
Stable Flow: Consistent and reliable hydraulic output ensures smooth system performance.
Versatile Applications: Suitable for various industrial, mobile, and automation hydraulic systems.
Vane pumps are typically packaged securely to prevent damage during transit. The packaging includes:
Protective Wrapping: To safeguard the pump from environmental damage.
Custom Crates: For larger, heavier pumps, ensuring safe handling.
Documentation: Includes installation, maintenance instructions, and warranty details.
Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.
| T6GCC | -B25 | -B27 | -6 | R | 02 | -B | 1 | 10 |
| Series | Flow-shaft end Pump | Flow-cover end Pump | Shaft type | Rotation | Port Positions | Design number | Sealing Level | Port dimensions |
| T6GC | B03、B05、B06、BO8、B10、B12、B14、B17、B20、B22、B25、B28、B31 | No | See size of shaft | Viewes from shaft end of pump R-right hand for clockwise L-left hand for clockwise | single pump Viewes from shaft end of pump 00-Opposite intle port 01-Inline with inlet 02-90°CCWfrom inlet 03-90°CW from inlet | A | 1-S1, NBR Nitrile rubber 5-S5,NBR Fluoro-rubber | 00:Flange 1"BSPP 01:SAE Flange SAE 4bolts(UNC) See installation dimensions |
| T7GB | B02、B03、B04、B05、 BO6、B07、B08、B10、B12、B15 | |||||||
| T6GCC | B03、B05、B06、B08、 B10、B12、B14、B17、 B20、B22、B25、B28、B31 | B03、B05、B06、B08、 B10、B12、B14、B17、 B20、B22、B25、B28、B31 | Double pump See picture below | B | 00,01,10,11 See installation dimensions | |||
| T67GCB | BO3、B05、BO6、B08、B10、B12、B14、B17、B20、B22、B25、B28、B31 | B02、B03、B04、B05、 BO6、B07、B08、B10、B12、B15、 B20 | ||||||
| T7GBB | B02、B03、B04、B05、 BO6、B07、B08、B10、B12、B15、 B20 | B02、B03、B04、B05、 BO6、B07、B08、B10、B12、B15、 B20 |
1. Industrial Hydraulic Systems
2. Mobile Equipment
3. Construction and Engineering Machinery
4. Metallurgy and Steel Industry
5. Marine and Offshore Equipment
All vane pumps are manufactured in compliance with international standards, ensuring high performance and reliability:
ISO 9001: Certified for quality management systems.
CE Certification: Ensures compliance with European safety, health, and environmental protection standards.
RoHS Compliance: Ensures the pump does not contain hazardous materials.
Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
We are a manufacture for vane pumps。.We are located in Changzhou City, Jiangsu Province, China.Welcome to visit us.
Factory established in 2005;
With a great deal of production experience;
80+ employees become the professional team;
Constant updated ERP system ensure efficiency of work;
Sophisticated equipment ehanced the accuracy of products;
Professional salesmen provide the greast service;
With a large number of famous customers all over the world;
Great after-sales service;
With the long term cooperation with famous logistics and express company in China,provide the better goods service.
Small order/sample order,full payment in advance; Big orders send the first payment 30% before the production,and the balance before shippment.We'll show the photos of the products and packages before delivery.
Of course we can. Just send me your logo we can make it for you.
America(40.5%):USA, Canada, Argentina, Brazil
Europe(30.8%):Italy,Germany,England,Holland,Spain,Swiss,Finland,Russia,Poland.
Asia(23.5%):Korea,singapore,India,Turkey,Vietnam,Saudi Arabia,Syria, Israel,Lebanon.
Others(5.8%).
The Green hydraulic pump manufacturing facility is a specialized industrial plant that focuses on producing hydraulic pumps and related components. These factories are equipped with advanced machinery and technology to fabricate high-quality pumps designed for a wide range of applications, from heavy equipment and machinery to automotive and industrial systems.
The production process typically involves precision engineering, where raw materials like metals and alloys are processed into pump components such as gears, pistons, cylinders, and seals. These parts are then assembled into fully functional hydraulic pumps, which are tested for performance and quality control to ensure reliability, efficiency, and durability under various working conditions.
All hydraulic pumps produced by Green Hydraulic have undergone compliance testing, ensuring their quality and reliability.
To meet the diverse needs of different industries, the green hydraulic offer customization options, such as specialized seals, materials, and pump configurations. These facilities often work closely with engineering teams to develop tailored solutions for specific applications, from high-pressure systems to low-flow, high-efficiency pumps.
