P330 Series Gear Pump overview
The P330 Series Gear Pump is a heavy‑duty, fixed‑displacement external gear hydraulic pump designed for demanding mobile and industrial applications. It features a robust cast‑iron construction with precision internal gears and bearings, delivering high pressure capability (up to ~241 bar / 3500 psi) and reliable performance over a wide speed range (up to ~3000 rpm). Available in a variety of displacements and standard SAE mounting and shaft options, the P330 is suitable for single, tandem or multiple pump configurations, making it adaptable for integration into diverse hydraulic systems. Widely used in sectors such as construction machinery, material handling, agriculture and heavy vehicles, this series provides stable flow, durability and versatility for continuous hydraulic power demands.
Key Features
Fixed‑displacement external gear design for consistent, stable flow output.
Heavy‑duty cast iron construction for strength and long service life.
Precision‑machined gears and internal components for smooth and efficient operation.
Wide range of displacement options to match various flow requirements.
Standard SAE mounting flanges and multiple shaft configurations for easy integration.
Available in single, tandem, and multi‑section configurations to support complex hydraulic systems.
Bi‑directional rotation options on select models.
High pressure and speed capability, suitable for demanding hydraulic workloads.
Advantages
Reliable and stable performance under continuous operation.
Excellent durability and wear resistance in heavy‑duty environments.
High volumetric and mechanical efficiency with reduced internal leakage.
Flexible installation and system design, thanks to modular configurations.
Easy service and maintenance with widely available parts.
Broad application compatibility — ideal for construction equipment, agricultural machinery, industrial power units, heavy vehicles, and municipal machinery.
Application
1. Industrial Hydraulic Systems
2. Mobile Equipment
3. Construction and Engineering Machinery
4. Metallurgy and Steel Industry
5. Marine and Offshore Equipment
Packaging & Delivery
Gear pumps are typically packaged securely to prevent damage during transit. The packaging includes:
Protective Wrapping: To safeguard the pump from environmental damage.
Custom Crates: For larger, heavier pumps, ensuring safe handling.
Documentation: Includes installation, maintenance instructions, and warranty details.
Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.
| CODE | 05 | 06 | 07 | 10 | 12 | 15 | 17 | 20 |
| Gear Wodth | 1/2" | 5/8" | 3/4" | 1" | 1-1/4" | 1-1/2" | 1-3/4" | 2" |
| Theoretlcal Displacement | 0.99 | 1.23 | 1.48 | 1.97 | 2.46 | 3.96 | 3.45 | 3.94 |
| 16.1 | 20.2 | 24.2 | 32.3 | 40.4 | 48.4 | 56.5 | 64.6 |
| Max Pressure Continuous | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3250 | 3000 |
| 245 | 245 | 245 | 245 | 245 | 245 | 225 | 210 |
| Max Pressure Intermittent | 4000 | 4000 | 4000 | 4000 | 4000 | 3850 | 3500 | 3300 |
| 275 | 275 | 275 | 275 | 275 | 265 | 245 | 225 |
| Speed RPM | 400-3000 |
Certifications & Quality Assurance
All vane pumps are manufactured in compliance with international standards, ensuring high performance and reliability:
ISO 9001: Certified for quality management systems.
CE Certification: Ensures compliance with European safety, health, and environmental protection standards.
RoHS Compliance: Ensures the pump does not contain hazardous materials.
Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
| Speed RPM | Gear width Output(gpm/lpm)and Inches(HP/KW) |
| 1/2" | 3/4" | 1" | 1-1/4" |
| 245bar | 245bar | 245bar | 245bar |
| Flow | Power | Flow | Power | Flow | Power | Flow | Power |
| 900 | 12 | 6 | 19 | 10 | 26 | 13 | 33 | 16 |
| 3.2 | 9 | 5.1 | 13 | 7 | 17 | 8.8 | 21 |
| 1200 | 17 | 8 | 26 | 13 | 36 | 17 | 45 | 21 |
| 4.5 | 11 | 7 | 17 | 9.5 | 23 | 12 | 28 |
| 1500 | 22 | 11 | 34 | 16 | 46 | 21 | 57 | 26 |
| 5.8 | 14 | 8.9 | 21 | 12.1 | 28 | 15.2 | 35 |
| 1800 | 27 | 13 | 41 | 19 | 55 | 25 | 70 | 32 |
| 7.1 | 17 | 10.8 | 26 | 14.7 | 34 | 18.4 | 43 |
| 2100 | 32 | 15 | 48 | 22 | 65 | 30 | 82 | 37 |
| 8.4 | 20 | 12.7 | 30 | 17.2 | 40 | 21.6 | 50 |
| 2400 | 36 | 17 | 55 | 25 | 75 | 34 | 94 | 42 |
| 9.6 | 23 | 14.7 | 34 | 19.8 | 45 | 24.8 | 57 |
| 3000 | 46 | 21 | 70 | 32 | 94 | 42 | 118 | 53 |
| 12.2 | 28 | 18.5 | 43 | 24.9 | 57 | 31.2 | 71 |
| Speed RPM | Gear width Output(gpm/lpm)and Inches(HP/KW) |
| 1-1/2" | 1-3/4" | 2" |
| 225bar | 220bar | 175bar |
| Flow | Power | Flow | Power | Flow | Power |
| 900 | 40 | 19 | 47 | 21 | 54 | 22 |
| 10.6 | 26 | 12.4 | 28 | 14.3 | 29 |
| 1200 | 55 | 25 | 64 | 25 | 73 | 29 |
| 14.5 | 34 | 16.9 | 37 | 19.4 | 39 |
| 1500 | 69 | 32 | 81 | 34 | 93 | 36 |
| 18.3 | 43 | 21.4 | 46 | 24.5 | 49 |
| 1800 | 84 | 38 | 98 | 41 | 112 | 44 |
| 22.1 | 51 | 25.9 | 55 | 29.6 | 58 |
| 2100 | 98 | 44 | 115 | 48 | 131 | 51 |
| 26 | 60 | 30.3 | 65 | 34.7 | 68 |
| 2400 | 113 | 51 | 132 | 55 | 151 | 58 |
| 29.8 | 68 | 34.8 | 74 | 39.8 | 78 |
| 3000 | 142 | 64 | 166 | 69 | 190 | 73 |
| 37.5 | 85 | 43.8 | 92 | 50.1 | 97 |
